PLA Antistatic
-
Color
-
-
Diameter
- 1.75mm
-
Weight
- 1kg
隐藏域元素占位
Surface Resistivity：10³-10⁵ Ω.cm
PLA anti-static wire is a functional 3D printing material that adds anti-static agents to traditional PLA, and has the following core characteristics:
1. Electrostatic protection: The surface resistance is significantly reduced (10 ^ 6-10 ^ 9 Ω), effectively eliminating the problem of electrostatic adsorption on printed parts and protecting sensitive electronic components.
2. Precision printing: retaining the excellent dimensional stability of PLA (shrinkage rate<0.3%), strong interlayer bonding, suitable for high-precision molding of 0.1mm.
3. Industrial compatibility: Printing temperature of 190-210 ℃, compatible with over 90% FDM equipment, supports high-speed printing of 50-100mm/s.
4. Dual effect environmental protection: The substrate is biodegradable PLA, the anti-static agent meets RoHS standards, and there is no heavy metal pollution.
5. Multi functional applications: Especially suitable for anti-static scenarios such as electronic fixtures, chip trays, laboratory consumables, etc., with surface resistance fluctuations<15%.
Note: It is recommended to control the humidity of the printing environment at 40-60% to optimize the anti-static effect.
★Printing Parameters
·Filament Diameter: 1.75mm
·Tolerance: ±0.05mm
·Printing Parameters
1.Long-distance Wire Feeding Printing
·Printing Temperature: 210-225℃
Recommendation Temperature: 220℃
·Heated Bed Temperature: 30-60℃
·Summer: 30-40℃ ·Winter: 55-60℃
·Special Bed Temperature: 60℃
·Printing Speed: 30-60mm/s
·Retraction Distance: 0-6mm/s
·Retraction Speed: 45-80mm/s
·Idling Speed: 70-100mm/s
2.Short-distance Wire Feeding Printing
·Printing Temperature: 215-225℃
Recommendation Temperature: 215℃
·Heated Bed Temperature: 30-60℃
·Summer:30-40℃ ·Winter:55-60℃
·Special Bed Temperature: 60℃
·Printing Speed: 30-60mm/s
·Retraction Distance: 0-6mm/s
·Retraction Speed: 45-80mm/s
·Idling Speed: 70-100mm/s
·Net Weigh: 1KG/ roll
·Gross Weight: 1.3KG/ roll
·Length：1.75MM(1KG)=335M
2.85MM(1KG)=125M
