TPE 39D

UV resistant, ozone resistant, and able to maintain stability in harsh environments; Good anti-aging performance and long service life; High elasticity, capable of restoring to its original state; Excellent tear resistance and wear resistance; Good tensile performance, high elongation at break; Soft to the touch, with a rubber like feel; Wide range of hardness, products with different hardness can be customized according to needs; Can maintain good flexibility and elasticity under low temperature conditions; Easy to use injection molding, extrusion molding, and other conventional plastic processing techniques; No toxic substance emissions during the processing, environmentally friendly and safe.

Color
Diameter
- 1.75mm
Weight
- 1kg

E-mail：tinawang852@gmail.com

WhatsApp：+8615356652384

加入购物车

立即购买

隐藏域元素占位

Description Parameters Model Download FAQ

★ Product Features
TPE elastomer filaments are made of low melting point TPE composite materials that have been specially polymerized and modified. The melting point of 39D is around 175 ℃. Compared to TPU elastomer consumables, this filament has better fluidity and lower water absorption rate. During the printing process, there is less wire drawing, resulting in lower sensitivity to temperature and faster printing speed compared to TPU with the same hardness. The printed product can withstand a heat resistance temperature of over 100 ℃ under stress free conditions.
1. Due to its softness, TPE in 1.75mm diameter is not suitable for 3D printers with remote wire feeding. Recommend a short-range wire feeding printer, the shorter the wire feeding distance of the printer, the better the products will be.
2. Due to the softness of TPE, traditional spring pressure wire feeding structures are prone to flattening filaments and unstable wire feeding in 3D printer extruder structures. Therefore, it is recommended to use a fixed distance dual wheel wire feeding structure.
3. Due to the softness of TPE, the channel from the extruder to the nozzle needs to be closed, otherwise it cannot be fed.
4. Due to the high molding shrinkage rate of TPE, it is recommended to establish a base during printing to prevent edge warping. At the same time, it is recommended to reduce the cooling speed or not turn on the cooling fan when establishing the base.

★ Printing Parameters
·Filament Diameter: 1.75mm

·Tolerance: ±0.05mm

·Printing Parameters
·Printing Temperature: 220-245℃
·Printing Speed:20-40mm/s
·Idling Speed: 70-100mm/s
·Heated Bed Temperature:60-80 ℃
·Net Weigh: 1KG/ roll

·Gross Weight: 1.3KG/ roll
·Length：1.75MM(1KG)=335M

2.85MM(1KG)=125M

Zhuopu Product Manual English Version

文件下载

Q1. Where is your factory located?

A1: We are a manufacturer, located in 88 Feicui Road, Jinnan street, Lin'an District, Hangzhou city, China.

Q2. Do you have any certificate on your 3D printer filament?

A2: Yes, all of our products have CE,FCC,certificate and ROHS certificate

Q3. Can I get free samples?

A3: Yes, some samples are free for customer, but you need to pay for the express fee. More details please send message to our sales service.

Q4. What is the MOQ for 3D Printer filament order?

A4:500g filament free(not for freight) for sample checking is available, After sample confirmation, a small order trial opportunity can be provided. But the MOQ for formal ordering is 500KG.

Q5. Can you put my brand name (logo) on these products?

A5: Yes, of course. We have 10 years of OEM manufacturing experience. For more detail please send message to our sales service.

Q6: What package do you use for the products?

A6: Usually we have professional retail package for the products.Food grade Vacuum bag & desiccant inside, then in carton.

Q7. Can we visit your factory?

A7: Yes.Warmly welcome you visit our factory . Due to too many visiting requirements, Please make an appointment with our sales service. Customers who have placed an ordered will have priority.

Q8. How do you ship the goods and how long does it take to arrive?

A8: lt's about 5-7 days for air freight, 3-5 days for international express. 20-40 days for sea transportation,this also depend on your area.

Q9. What payment method do you accept?

A9: We are acceptable T/T, L/C, Paypal,Credit Card, Alipay etc. (Usually we adopt T/T term. 30% T/T in advance as deposit,70% balance payment before shipment.) If you have other inquiries, please contact us to talk more.

Q10. How about your support and after-sales:

A10: For all the products, we have one-year warranty.All of our goods are 100% tested working before sent to you.In case there are unexpected damages during delivery, please do check before yousign for the package. We have been committed to producing high-quality products and providing customers with a good experience. If there is any quality problem, we will definitely solve the problem until you are satisfied.

Q11. How to order?

A4:1.Please tell us which filament type,Quantitiy,color you want to order. 2. Tell us your details address with zip code.( if by sea pls tell us your sea port ) 3. We will make PI(perform invoice) with shipping cost for your order to confirm. 4. Checking the PI, we will delivery the goods to Shipper for you when we receive your payment. 5 The shipping cost is depending on the weight.if take by sea depends on volume CBM ( cubic meters ) Or please click the "contact supplier" at the right side of this page or contact our sales on Trade Manage online or by e-mail!
