PBT CF(Carbon Fiber)
-
Color
-
-
Diameter
- 1.75mm
-
Weight
- 1kg
隐藏域元素占位
The composite material of PBT (polybutylene terephthalate) and carbon fiber combines the advantages of high-performance engineering plastics and reinforcing fibers, and has the following characteristics:
1. High strength and rigidity: Carbon fiber significantly enhances the mechanical properties of PBT, giving it high tensile strength and modulus, making it suitable for structural components;
2. Lightweight: Low density, lighter than metal, suitable for weight reduction needs in fields such as automotive, aerospace, etc;
3. Heat resistance: PBT itself is resistant to high temperatures (long-term use temperature can reach over 120 ° C), and carbon fiber further improves thermal stability;
4. Chemical corrosion resistance: has good resistance to oil agents, solvents, etc., suitable for harsh environments;
5. Dimensional stability: low moisture absorption, not easily deformed, ensuring the reliability of precision components;
6. Conductivity: Carbon fiber endows the material with certain conductivity and anti-static properties.
Widely used in high-performance demand scenarios such as electronic casings, automotive components, and sports equipment.
★Printing Parameters
·Filament Diameter: 1.75mm
·Tolerance: ±0.05mm
·Printing Parameters
·Printing Temperature: 235-265℃
·Printing Speed:30-60mm/s
·High-speed Printing Speed:200-360mm/s
·Idling Speed: 70-100mm/s
·Heated Bed Temperature:0-60 ℃ (special bed require heating)
·Net Weigh: 1KG/ roll
·Gross Weight: 1.3KG/ roll
·Length：1.75MM(1KG)=320M
2.85MM(1KG)=120M
